Rail Mounted Container Gantry Crane
Key Information
Lifting Capacity:
35t, 40t, 50t (customizable)
Span:
22m–35m or based on customer requirements
Lifting Height:
12.3m–20m (customizable)
Working Class:
A5–A8
Lifting Speed Options:
8; 8/0.8; 7/0.7; 3.5/0.35; 4; 4/0.4; 3; 3/0.3 (depending on model)
Widely Used In:
Rail freight terminals, container ports
Overview
Rail Mounted Container Gantry Crane
Rail mounted container gantry cranes are rail-traveling cranes designed primarily for container handling, loading/unloading, and stacking operations in container terminals and intermodal yards.
Key Features
Intro
The Rail Mounted Container Gantry Crane (RMG) is a specialized gantry crane designed for container terminals, rail freight stations, and large logistics yards. It operates along fixed rails and is powered by electrical cable systems, usually through cable reels. This crane is equipped with telescopic spreaders (20′, 40′, 45′), and in some configurations, dual spreaders for more efficient stacking and movement of standard ISO containers.
The crane system consists of a steel gantry frame, hoisting mechanism, trolley traveling mechanism, crane traveling mechanism, container spreader with anti-sway technology, and an integrated electrical control system. It is typically operated via a driver’s cabin but can also support semi-automated or fully automated control depending on site needs.
There are three structural variants depending on operational requirements: cantilever on one side, both sides, or no cantilever.
RMG cranes are known for clean electric drive, large lifting capacity, stable performance, high efficiency, and low maintenance.
advantages
- High Load Capacity: Engineered to handle heavy-duty containers of various sizes and weights.
- Advanced Automation: Can be integrated with yard automation systems for unmanned operation, enhancing efficiency and reducing labor cost.
- Accurate Positioning: Equipped with a PLC system for precise container placement, ensuring safe and efficient loading/unloading.
Faqs
How can I choose right cranes?
We have 24-hour online customer service to provide you with professional consulting services and help you choose the right crane according to your working conditions.
Are your cranes customizable?
Yes, we support customization to meet specific lifting requirements. Factors such as lifting capacity, span length, lifting height, and control options can be tailored to suit your needs of the industry or application. Customization ensures optimal performance and efficiency.
I have low headroom in my workshop, is it possible to install a crane in it?
We have special products for low headroom workshop, our engineer can give the best design according to your dimensions.
What kind of package for Hoist or Cranes?
Hoists and Electricals packed in fumigation wooden box. Main beams covered by woven plastic cloth.
When the main girder is too long, how to delivery by container?
The main girder will be divided into different pieces, each part’s length is within 11.8m. When client receive the goods, just connect them with high strength bolt is okay.
How can you provide after-sale service?
This is a common concern for customers. We provide one-stop service, from delivery, installation to after-sales. We will have online customer service ready to solve your problems at any time, we also provide after-sales documentation support, such as operation manuals, maintenance manuals, etc. If the problem still not be solved, we can send our engineers to your site.
Can we get on-site guided installation service?
Of course, we also have a professional team of technicians responsible for equipment installation and training guidance, and we can provide you with on-site installation and testing guidance.
