Single-Girder Overhead Crane Exported to a Steel Processing Workshop in Saudi Arabia

case

Single-Girder Overhead Crane Exported to a Steel Processing Workshop in Saudi Arabia

We specialize in providing customized crane systems for global industries such as steel fabrication, machinery manufacturing, and warehouse logistics. Through European-standard designs, smart control systems, and modular engineering, we help clients achieve efficient, safe, and intelligent production goals.

asic Project Information

Product Name

European Single-Girder Overhead Crane

Lifting Capacity

8+8 tons (dual-hook synchronized lifting)

Span

24.7 meters

Lifting Height

8 meters

Working Class

FEM 2M / ISO M5

Lifting Mechanism

European low-headroom wire rope electric hoists (dual trolley)

Control Mode

Wireless remote + pendant control

Power Supply

Conductor rail

Installation Type

Overhead rail-mounted installation across the workshop

01-Project Overview

In January 2025, our company successfully exported a European-style single-girder overhead crane to a steel processing enterprise in Dammam, Saudi Arabia. The system features a dual-hook configuration (8+8 tons), designed for lifting and transporting steel profiles and plates within the workshop. Due to limited headroom in the facility, the client required a compact crane structure with high-precision synchronized lifting capabilities.

02-Industry Background

Steel processing workshops often involve synchronous handling of heavy materials such as steel plates, profiles, and H-beams. These operations demand lifting equipment with high precision, synchronization, structural strength, and performance for frequent use. The customer’s existing crane was a single-hook model, which led to swaying loads and safety concerns. An upgrade to a more efficient and safer European dual-hook crane system was urgently needed.

03-Customer Requirements

Synchronous lifting of heavy steel materials to prevent load imbalance
Stable operation and structural integrity across a long span (24.7 m)
Compact structure with low headroom design to fit the limited space
Capability to operate under high-frequency, heavy-duty conditions
Flexible control system suitable for multi-operator usage via wireless remote

04-Solution

We provided a customized European-style single-girder dual-hoist crane solution, featuring two low-headroom electric wire rope hoists with synchronized control to ensure smooth and safe dual-point lifting. The crane’s structure was optimized for the 24.7-meter span, with a lightweight and stress-optimized main beam to enhance performance while reducing energy consumption. The control system includes intelligent monitoring modules and reserved remote interfaces, enabling future digital upgrades.

05-Project Highlights

Synchronized Dual-Hook Lifting: Two electric hoists operate in precise synchronization to ensure stable load handling
Long-Span Structural Design: 24.7-meter main beam with high strength and smooth operation
Compact Layout: Low-headroom hoists maximize vertical lifting range within limited workshop height
Heavy-Duty Ready: M5 working class supports high-frequency, continuous-duty operations
Highly Rated by Client: After commissioning, the client reported a 30% improvement in lifting efficiency and plans to order 2 additional sets for a new workshop

Customer Compliments

The quality of overhead cranes we purchased was excellent. During the use of the crane, we have not encountered any quality problems, which proves your company’s strict quality control. We are very satisfied with your products and look forward to establishing a long-term cooperative relationship with you.
